Stainless steel round bars and rods are essential components in various industrial applications, including construction, manufacturing, and transportation. At Icon Steel, we are committed to providing high-quality stainless steel round bars and rods that are designed to meet the unique needs of our clients.
One of the key features of our stainless steel round bars and rods is their excellent resistance to corrosion. Stainless steel contains chromium, which reacts with oxygen to form a protective layer on the surface of the material. This layer helps to prevent corrosion and makes stainless steel round bars and rods ideal for use in harsh environments.
Another important feature of our stainless steel round bars and rods is their high strength-to-weight ratio. Stainless steel is known for its strength and durability, which makes it a popular choice for heavy-duty applications where the material is subjected to constant stress.
At Icon Steel, we offer a wide range of stainless steel round bar and rod sizes and thicknesses to meet the diverse needs of our clients. Our stainless steel round bars and rods are available in various finishes, including mirror, brushed, and satin, to meet different aesthetic preferences.
Key Features
Stainless Steel Black Bar vs Stainless Steel Forged Bar
There are several types of stainless steel bars available on the market, including stainless steel black bars and stainless steel forged bars.
Stainless steel black bars, also known as hot rolled bars, are produced by heating stainless steel billets to very high temperatures and then rolling them into their final shape. The resulting bars have a dark, rough surface and are typically used in applications where appearance is not a critical factor.
On the other hand, stainless steel forged bars are produced by shaping heated stainless steel billets using a forging press or hammer. This process results in bars with a smooth, polished surface and improved mechanical properties, such as higher strength and toughness, compared to black bars. Forged bars are often used in applications where appearance and performance are both important.
Cold Drawn Stainless Steel Round Bars
Icon steel that in the production of high quality stainless steel bars, including cold drawn stainless steel bars. Cold drawing is a process used to produce precision-sized bars with a smooth, polished surface finish.
The process starts with hot rolled steel bars that are cleaned and coated with a lubricant to prevent rust and facilitate the drawing process. The bars are then pulled through a series of dies at room temperature, which reduces their diameter and increases their length. This process results in a bar with a uniform diameter and a smooth, polished surface.
One of the key benefits of cold drawn stainless steel bars is their high dimensional accuracy and consistency. The cold drawing process allows for tighter tolerances and a more precise control over the final size and shape of the bar. This makes them ideal for use in applications where precision and accuracy are critical, such as in the aerospace, medical, and automotive industries.
Polished Stainless Steel Round Bars
Polished stainless steel bars are stainless steel bars that have undergone a polishing process to achieve a smooth and reflective surface finish. The polishing process involves using abrasive materials and polishing compounds to remove surface imperfections and create a uniform surface texture.
Polished stainless steel bars are often used in applications where appearance and aesthetics are important, such as in architecture, interior design, and high-end furniture. The smooth and reflective surface finish gives these bars a clean and modern look that can enhance the visual appeal of any space.
Specification
| Parameter | Details |
|---|---|
| Product Name | Stainless Steel Bar |
| Length | As required |
| Diameter | As required |
| Thickness | As required |
| Standard | ASTM A276, ASTM A479, EN 10088-3 |
| Technique | Hot Rolled, Cold Drawn |
| Surface Treatment | Polished, Annealed, Pickled |
| Material | SUS304, SUS316, SUS321 |
| Application | Construction, automotive, machinery, medical, food processing |
| MOQ | Generally 5-10 metric tons depending on specifications |
| Shipment Time | Within 15-30 days after order confirmation |
| Export Packing | Standard seaworthy packing |
| Capacity | 500 metric tons per month |
Chemical Composition
| Grade | C% (max) | Mn% (max) | P% (max) | S% (max) | Si% (max) | Cr% | Ni% | Mo% |
|---|---|---|---|---|---|---|---|---|
| SUS304 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 18.0-20.0 | 8.0-10.5 | - |
| SUS316 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| SUS321 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0-19.0 | 9.0-12.0 | - |
Mechanical Properties
| Grade | C% (max) | Mn% (max) | P% (max) | S% (max) | Si% (max) | Cr% | Ni% | Mo% |
|---|---|---|---|---|---|---|---|---|
| SUS304 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 18.0-20.0 | 8.0-10.5 | - |
| SUS316 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
| SUS321 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 17.0-19.0 | 9.0-12.0 | - |
Stainless Steel Round Bars and Rods Specification
| Parameter | Details |
|---|---|
| Stainless steel Bar Specification | EN 10272, EN 10088-3 |
| Standard | SUS, GB, ASME, EN, API, DIN, ASTM, AISI, UNS |
| Sizes | 3mm to 800mm diameter |
| Length | "12 Random Lengths Long Bars: 15-20 Random Lengths" |
| Finish | Bright, Rough Turned, Peeled, Cold Drawn Turned, Polished, Annealed, Bright Drawn, Centreless Ground, Black, Grinding, Smooth Turned |
| Tolerances | K12, H12, K11, H9, H13, H11, K9, H10, K10, H8 |
| Surface Finish | NO.1, 2B, NO.4, HL, 2D, 1D, 8K, NO.3, BA |
| Production Method | Rolled / Forged |
| Stainless Steel Round Bar Characteristics | *Cold Working of SS Bars: Good *SS Rod Corrosion Resistance: Excellent *High tensile SS Round Bars Heat Resistance: Good *Heat Treatment of Brushed SS Bars: Poor *Austenitic SS Bars Hot Working: Fair *Free-machining SS Round Bars Machinability: Good *Austenitic Steel Bars Weldability: Very Good* |
| Value Added Services at Om Steel | *Heat Treatment *Production Bar Cutting *Chemical Milling *Turn, Ground, and Polishing *Surface Machining *Shearing *Precision Grinding *Trepanning *Rigidizing *Custom Packing* |
| Other available forms | Triangle, Half Round, Rod, Precision Ground, Angle, Channel, Rounds, Rectangle, Hollow, T-Bar, Billet, Profiles, I/H, Blocks, Forging, Threaded, Ingot |
Stainless Steel Round Bars Weight Per Foot
| Diameter | Weight | ||
|---|---|---|---|
| (inches) | per metre (kg) | (mm) | per metre (kg) |
| 1/8 Inch | 0.06 | 3 mm | 0.06 |
| 3/16 Inch | 0.14 | 4 mm | 0.1 |
| 1/4 Inch | 0.25 | 5 mm | 0.16 |
| 5/16 Inch | 0.39 | 6 mm | 0.22 |
| 3/8 Inch | 0.56 | 7 mm | 0.3 |
| 7/16 Inch | 0.77 | 8 mm | 0.4 |
| 1/2 Inch | 1 | 10 mm | 0.62 |
| 9/16 Inch | 1.22 | 12 mm | 0.89 |
| 5/8 Inch | 1.56 | 14 mm | 1.22 |
| 11/16 Inch | 1.89 | 15 mm | 1.4 |
| 3/4 Inch | 2.25 | 16 mm | 1.59 |
| 7/8 Inch | 3.07 | 18 mm | 2.01 |
| 1 Inch | 4.03 | 20 mm | 2.48 |
| – | – | 22 mm | 3.00 |
| – | – | 24 mm | 3.57 |
| – | – | 25 mm | 3.88 |
Stainless Steel Round Bars Tensile Strength
| Grade | Tensile Strength | Cold Drawn | Other |
|---|---|---|---|
| EN 1.4301 | Mpa | 680 | 590 |
| EN 1.4401 | Mpa | 680 | 590 |
Cold Finished Stainless Steel Round Bars tolerances
| Cold Finish | Inches | Tolerance (+/- inches) |
|---|---|---|
| Cold Finish | 0.0625 to 0.3125, excl | 0.001* |
| Cold Finish | 0.3125 to 0.500, excl | 0.0015* |
| Cold Finish | 0.500 to 1, excl | 0.002* |
| Cold Finish | 1 to 1.5, excl | 0.0025* |
| Cold Finish | 1.5 to 3.25, incl | 0.003* |
| Cold Finish | 3.25 to 4, incl | 0.005* |
Hot Rolled Stainless steel Round Bar tolerances
| Hot Rolled | Inches | Tolerance (+/- inches) |
|---|---|---|
| Hot Rolled | Over 2.5 to 3.5, incl | + 3/64" |
| Hot Rolled | Over 3.5 to 4.5, incl | + 0.0625" |
| Hot Rolled | Over 4.5 to 5.5, incl | + 5/64" |
| Hot Rolled | Over 5.5 to 6.5, incl | + 0.125" |
| Hot Rolled | Over 6.5 to 8, incl | + 5/32" |
| Hot Rolled | Over 8 to 12, incl | + 0.1875" |
| Hot Rolled | Over 12 to 15, incl | + 7/32" |
Dive into our comprehensive product gallery to see the wide range of stainless steel products we offer. Each product is designed to meet the highest standards and cater to various applications across different industries. Below, you will find images and brief descriptions of each product category to help you choose the right one for your project.
Call expert
+971 55 309 9915
Write email
info@iconsteel.ae
Visit office
Burjuman Business Tower BT 20-10, Khalid Bin Walid Road, Dubai, UAE
Applications of Stainless Steel Pipe/Tube
Stainless steel bars are integral in the construction industry, used for structural supports, railings, and frameworks due to their strength and resistance to environmental factors.
In the automotive sector, stainless steel bars are utilized for manufacturing components and parts, providing durability and resistance to corrosion.
The medical industry relies on stainless steel bars for surgical instruments and medical devices, benefiting from their biocompatibility and ease of sterilization.
Essential for machine parts and industrial equipment, stainless steel bars ensure robust performance and longevity in high-stress environments.
Ideal for food-grade equipment and utensils, stainless steel bars prevent contamination and ensure hygiene in food processing applications.
FAQ
Stainless steel round bars and rods are typically manufactured using one of two methods: hot rolling or cold drawing. Hot rolling involves heating the steel to a high temperature and then rolling it into the desired shape, while cold drawing involves pulling the steel through a die to achieve the desired diameter and shape.
There are many different grades of stainless steel that are used for round bars and rods, including 304/304L, 316/316L, 410, and 416. Each grade has its own unique properties and characteristics, making it suitable for specific applications. Know more
Stainless steel round bars and rods can be finished in a variety of ways, including polished, brushed, and satin finishes. Each finish has its own unique appearance and texture, and the choice of finish will depend on the intended application of the bar or rod. Know more.
Stainless steel round bars and rods offer several benefits, including excellent corrosion resistance, high strength, durability, and an attractive appearance. They are also easy to clean and maintain, making them a popular choice for a variety of applications.
Stainless steel has a minimum chromium content of 10.5%, as well as low levels of carbon (less than 1.2%) and other alloys. By adding other elements like nickel, molybdenum, titanium, niobium, manganese, etc., the corrosion resistance and mechanical properties of stainless steel can be improved even further.
There are several grades of stainless steel sheets available, with some of the most common being 304, 316, 430, and 409. 304 is a widely used austenitic stainless steel with good corrosion resistance and formability.
Stainless steel sheets from Omsteel have a wide range of applications, including in the construction industry for cladding, roofing, and structural components, in the automotive industry for exhaust systems and trim, in the food processing and medical industries for equipment and utensils, and in the aerospace industry for structural components and aircraft exhaust systems.
The Price of Stainless steel depends on the size, Grade, Thickness and other properties. Contact us now to know more.
