Icon Steel specializes in producing Monel tubes for use in high-performance and complex operating conditions. This tubing finds wide applications in industries like processing chemicals, in the oil and gas sector, and in marine engineering owing to its high resistance to corrosion and mechanical strength.
Key Features
Specification
| Specification | Details |
|---|---|
| Material Composition | Nickel (63-70%), Copper (28-34%), Iron (1-3%), Manganese (2%) |
| Yield Strength | 240-345 MPa |
| Tensile Strength | 520-620 MPa |
| Elongation | 30-35% |
| Corrosion Resistance | Superior resistance to acidic and alkaline environments |
| Wall Thickness Range | 0.5 mm to 20 mm |
| Outer Diameter Range | 6 mm to 250 mm |
| Length | Up to 6 meters |
| Standards Compliance | ASTM B165, AMS 4574, ASME SB-165 |
| Surface Finishes | Bright Annealed, Polished, Pickled |
| Available Coating | Passivation, Electropolishing |
| Operating Temperature Range | -129°C to +550°C |
Chemical Properties
| Element | Percentage (%) |
|---|---|
| Nickel (Ni) | 63-70% |
| Copper (Cu) | 28-34% |
| Iron (Fe) | 1-3% |
| Manganese (Mn) | 2% |
| Silicon (Si) | 0.5% |
| Carbon (C) | 0.3% |
Mechanical Properties
| Mechanical Property | Value |
|---|---|
| Tensile Strength | 520-620 MPa |
| Yield Strength | 240-345 MPa |
| Elongation at Break | 30-35% |
| Hardness | 65-85 HRB |
| Impact Strength | 70-100 J (at -20°C) |
Dive into our comprehensive product gallery to see the wide range of stainless steel products we offer. Each product is designed to meet the highest standards and cater to various applications across different industries. Below, you will find images and brief descriptions of each product category to help you choose the right one for your project.
Call expert
+971 55 309 9915
Write email
info@iconsteel.ae
Visit office
Burjuman Business Tower BT 20-10, Khalid Bin Walid Road, Dubai, UAE
Industrial Applications of Monel Tube
Chemical Processing
Monel pipe fittings are used in heat exchangers, evaporators, and piping systems due to their exceptional resistance to acidic and alkaline media, ensuring durability and reliability in harsh chemical environments.
Marine Engineering
Monel fittings excel in saltwater piping, condensers, and heat exchangers, offering superior resistance to seawater corrosion, critical for marine applications.
Oil & Gas
Ideal for sour gas service, offshore drilling, and refinery components, Monel fittings withstand high pressures and resist corrosion from harsh substances, making them essential in the oil and gas sector.
Power Generation
In nuclear and thermal power plants, Monel pipe fittings are crucial for high-temperature and corrosive environments, ensuring long-term performance and safety.
FAQ
Monel Tubes reflect excellent resistance to corrosive chemicals, which make them perfect for handling acids and alkalis under abiding environments.
Yes, Monel tubes have good formability. Proper techniques can be applied in bending or shaping Monel tubes without compromising the structural integrity.
Icon Steel offers both passivation and electropolishing to provide an enhanced surface finish and corrosion resistance on Monel tubes.
These Monel tubes come in huge arrays of sizes, with the outer diameter ranging from 6 millimeters to 250 millimeters and the wall thickness from 0.5 millimeter to 20 millimeter.
