Monel forged fittings from Icon Steel are designed to provide better mechanical strength and resistance in the most adverse conditions. They are fabricated from top-grade Monel alloys and specifically designed for high-performance and long-life industries.
The makeup of Monel confers these forged fittings the ability to bear extreme temperatures, pressure extremes, and corrosive materials. That’s why they’re preferred in the most demanding applications.
Key Features
Specification
| Specification | Details |
|---|---|
| Material Composition | Nickel (63-70%), Copper (28-34%), Iron (2.5-5%), Manganese (up to 2%) |
| Yield Strength | 240-345 MPa |
| Tensile Strength | 550-750 MPa |
| Elongation | 20-35% |
| Corrosion Resistance | Excellent in acidic, alkaline, and marine environments |
| Thickness Range | 0.5 mm to 100 mm |
| Width and Length | Customizable as per requirement |
| Standards Compliance | ASTM B564, ASME SB564, DIN, EN |
| Surface Finishes | Smooth, Polished, Machined |
| Available Coating | Epoxy, Zinc, Chrome, Nickel plating |
| Operating Temperature Range | -100°C to 500°C |
Chemical Properties
| Element | Percentage (%) |
|---|---|
| Nickel (Ni) | 63-70% |
| Copper (Cu) | 28-34% |
| Iron (Fe) | 2.5-5% |
| Manganese (Mn) | Up to 2% |
| Silicon (Si) | 0.5% |
| Carbon (C) | 0.3% |
| Sulfur (S) | 0.024% |
Mechanical Properties
| Mechanical Property | Value |
|---|---|
| Tensile Strength | 550-750 MPa |
| Yield Strength | 240-345 MPa |
| Elongation at Break | 20-35% |
| Hardness | Rockwell B 75-85 |
| Impact Strength | High impact resistance |
Dive into our comprehensive product gallery to see the wide range of stainless steel products we offer. Each product is designed to meet the highest standards and cater to various applications across different industries. Below, you will find images and brief descriptions of each product category to help you choose the right one for your project.
Call expert
+971 55 309 9915
Write email
info@iconsteel.ae
Visit office
Burjuman Business Tower BT 20-10, Khalid Bin Walid Road, Dubai, UAE
Industrial Applications for Inconel Forged Fittings
Marine Engineering
Due to their excellent resistance to sea water and salt spray, Monel items are required in ship building, off-shore platform, and other marine applications.
Power generation
It can be helpful for high-temperature conditions like turbines and heat interchangers and reactors in a power station.
Aerospace
In this industry, the alloy is applied in high-temperature areas and on parts that require high strength.
Oil and gas industry standards
It is used in high-pressure pipes, valves, and other necessary equipment that goes directly in the process of drilling or extraction.
Chemical and Petrochemical Industries
They are required for handling corrosive chemicals, acids, and alkalis in chemical plants and refineries.
FAQ
Monel forged fittings show high corrosion resistance specifically to marine and chemical environments and also function well under high pressures and temperatures, thus are superior to most alloy fittings.
Yes, Monel forged fittings perform well in cryogenic applications, maintaining their mechanical properties at temperatures as low as -100°C.
Monel forged fittings are designed to withstand temperatures up to 500°C, making them suitable for high-temperature applications such as power generation and petrochemical processing.
Available coatings include epoxy, zinc, chrome, and nickel plating. The choice of coating depends on the application environment, with epoxy and zinc being ideal for enhanced corrosion protection, while chrome and nickel plating offer additional hardness and aesthetic appeal.
