Icon Steel’s Inconel Sheets are designed to meet the needs of industries working in the most severe environments. These sheets are particularly famous for their superior heat, oxidation, and corrosion resistance and are composed of a high-quality Inconel Alloy.
No matter if you are in the marine, chemical processing, or aerospace industry, our Inconel Sheets provide an excellent balance of performance and durability to ensure your operation will continue to perform in the harshest environments.
Key Features
Specification
| Specification | Details |
|---|---|
| Material Composition | Nickel (58-72%), Chromium (14-23%), Iron (3-5%), with trace amounts of Molybdenum, Aluminum, and Titanium |
| Yield Strength | 414 MPa |
| Tensile Strength | 827 MPa |
| Elongation | 30% |
| Corrosion Resistance | Excellent in both acidic and alkaline environments |
| Thickness Range | 0.5 mm to 50 mm |
| Width and Length | Customizable up to 2000 mm width and 6000 mm length |
| Standards Compliance | ASTM B168, ASME SB-168, ISO 6208 |
| Surface Finishes | Mill finish, Polished, Brushed, and Custom finishes |
| Available Coatings | Aluminide, Ceramic, and Custom Coatings |
| Operating Temperature Range | -196°C to 982°C |
Chemical Properties
| Element | Percentage (%) |
|---|---|
| Nickel (Ni) | 58-72 |
| Chromium (Cr) | 14-23 |
| Iron (Fe) | 3-5 |
| Molybdenum (Mo) | 2-3 |
| Aluminum (Al) | 0.4-1.5 |
| Titanium (Ti) | 0.4-1.2 |
| Carbon (C) | ≤ 0.08 |
| Silicon (Si) | ≤ 0.5 |
| Manganese (Mn) | ≤ 1.0 |
Mechanical Properties
| Mechanical Property | Value |
|---|---|
| Tensile Strength | 827 MPa |
| Yield Strength | 414 MPa |
| Elongation at Break | 30% |
| Hardness | Rockwell B88 |
| Impact Strength | 110 J |
Dive into our comprehensive product gallery to see the wide range of stainless steel products we offer. Each product is designed to meet the highest standards and cater to various applications across different industries. Below, you will find images and brief descriptions of each product category to help you choose the right one for your project.
Call expert
+971 55 309 9915
Write email
info@iconsteel.ae
Visit office
Burjuman Business Tower BT 20-10, Khalid Bin Walid Road, Dubai, UAE
Inconel Sheets applications
Aerospace Industry
Inconel Sheets are often used when developing turbine blades, heat shields, and aircraft exhaust systems because they are designed to function at higher temperatures and resist corrosive environments.
Marine Engineering
Inconel Sheets are beneficial in marine applications in which corrosion resistance is essential. For example, Inconel Sheets are used in seawater-service equipment and offshore platforms.
Chemical Processing
Inconel Sheets have applications in chemical processing, specifically in developing pressure vessels, heat exchangers, and piping systems that come into contact with corrosive chemicals and high heat.
Power Generation
Inconel Sheets have applications in the power generation industry. Specifically, manufacturers can utilize Inconel Sheets in gas turbine components and nuclear reactors because these sheets have high thermal and mechanical stability.
FAQ
Inconel Sheets by Icon Steel typically contain 58-72% Nickel, 14-23% Chromium, and 3-5% Iron, as well as additional alloying elements like Molybdenum, Aluminum, and Titanium to enhance material properties.
Yes, Icon Steel provides customizable thickness ranges from 0.5 mm to 50 mm. Moreover, Inconel Sheets can be cut to a maximum width of 2000 mm and a maximum length of 6000 mm to accommodate application-specific requirements.
Icon Steel offers several coating options, such as aluminides or ceramic coatings, to further enhance the oxidation and/or corrosion resistance of the Inconel Sheets.
Yes, Icon Steel’s Inconel Sheets comply with ASTM B168, ASME SB-168, and ISO 6208 standards. With compliance to these standards, Icon Steel’s Inconel Sheets are able to meet strict demands in the industrial market.
